01 Access
Two ways in: try it without a key, or sign in with the key you bought. Both open the same editor.
Trial
- Click Open the editor.
- Plan one room freely and try the automatic layout.
- Saving and printing are disabled in trial mode.
With a key
- Enter the key you received after purchase.
- The key is bound to your device (one key — one device).
- Saving and printing switch on; the program auto-saves every 30 seconds.
The editor runs at aaa777.eu — nothing to download, no special browser needed. The old file-based method is no longer valid.
02 Start from a floor plan
The whole building is built from the floor plan of a single storey. You upload it, the program recognises it — and multiplies the rest.
Upload the floor plan
A photo or image (JPG/PNG), PDF or DWG. A sharp, top-down drawing gives the best result.
The AI recognises the rooms
Walls, doors and windows fall into place. Fixtures drawn on the plan — bathtub, WC, basin — are kept as fact: the automatic layout never overwrites them. You can adjust the result by hand at any time.
Multiply the storeys
Set EMELET (floors) and LAKÁS/EM. (apartments per floor) — the recognised storey is copied to identical floors. One floor plan — a whole building.
| What you upload | What you get |
|---|---|
| Photo or image (JPG/PNG) | AI Vision: a full room-by-room layout |
| Technical PDF with a room schedule | Precise room-by-room import |
| Plain PDF (no room schedule) | Base layout — refine by hand |
| No drawing | Enter sizes by hand + built-in templates |
Floor-plan import is part of the Developer package.
03 The workflow
Order matters: furniture first, then lock, and only then the engineering disciplines.
Pick a room
Open a room from the list, or enter its dimensions by hand. If you started from a floor plan (02), the recognised rooms are already waiting in the list.
Design — furniture
On the 🎨 Design tab press 🤖 Auto-design (all systems) — furniture, doors and windows fall into place. Manual adjustment: ✋ Move → click the item → move it → click again. R rotates, Del deletes, 📚 Furniture library adds a new item.
Lock the plan
Once the furniture is in place, press 🔒 Lock plan. Unlock the same way: 🔓.
Engineering disciplines can only be added after the design is locked (🔒) — otherwise the tabs stay inactive.Engineering disciplines
After locking, four tabs open: ⚡ Electrical, 🔧 Plumbing, 🌀 HVAC, 🔥 Fire Safety. On each, run 🤖 Auto-design, then adjust by hand where needed.
Heating mode
Choose the room's heating: radiators, underfloor, air heating or local. The printed work sheet reflects the chosen mode.
Print
Use the 🖨 buttons to print a work sheet per room or in batch: material list, time norms, cost in forints and installation dimensions. (With a key.)
Save
💾 Save — the project goes into a .json file. 📂 Load — reload an earlier project. Always open the .json with the Load button, never directly.
04 Keyboard shortcuts
| Key | Action |
|---|---|
| R | Rotate the selected item by 90° (four positions). |
| Del / Backspace | Delete the selected item. |
| Esc | Cancel / close the library. |
| Scroll | Zoom in and out in the 3D view. |
05 FAQ
| Situation | Solution |
|---|---|
| The engineering tab is inactive | Lock the plan first: 🔒 Lock plan. |
| The item won't move | ✋ Move → click the item → move the mouse → click again. |
| I can't save or print | These are disabled in trial mode. Enter your key for full access. |
| The key is rejected (different device) | The key is bound to one device. To move it, write to us — we unlock it manually. |
| Red error screen | Note the exact error text and line number, and report it to us. |
| A discipline doesn't show on the plan | Run 🤖 Auto-design on that tab. |
| The AI didn't recognise the plan accurately | Use a sharper, top-down image. Recognised walls and items can be adjusted by hand — lock the plan after fixing. |
Ready?
Open the editor and plan your first room.
Open the editor30-minute trial, no key. Saving and printing with a key.
